Main Features:
·Continuous low pulsation conveying.
·Low mechanical vibration and noise.
·The flow rate is proportional to the rotational speed, suitable for metering purposes.
·Sanitary grade quick connection and quick change for import and export, easy to clean and maintain.
·Mirror polishing of overcurrent components, with good streamline and no dead corners or scaling.
Technical Parameters:
·The maximum flow rate can reach 140m3/h, and the maximum pressure can reach 48bar
·Rotor - Coated with anti-wear and corrosion-resistant design, providing multiple material options such as 304, 316, 316L, 2205, etc
·Stator - imported and specially formulated, providing a variety of material options such as food grade NBR, EPDM, FPM, etc
·Shaft seal - standard single end mechanical seal, low friction resistance, low and high temperature resistance, corrosion resistance, wear resistance, stable and reliable sealing effect. According to the actual working conditions, other types of single/double end mechanical seals, containerized or other types of mechanical seals can also be used, and the sealing of the packing can also be improved.
·Reducer - comes standard with R series helical gear hard tooth surface reducer, which has high load-bearing capacity, high efficiency, and long service life. It can be selected according to the customer's specified brand.
·Motor - Provides various forms of options such as three-phase AC, three-phase frequency conversion, three-phase explosion-proof, and three-phase frequency conversion explosion-proof. It can be selected according to the customer's specified brand and offers high-efficiency motor options.
·Sanitary interface - sanitary grade quick connect and quick change, easy to clean and maintain.
Application:
Transportation of various types of products and media such as chemical, lithium battery, pharmaceutical, and chemical products with cleaning requirements.
