Main Features:
·Continuous low pulsation conveying
·Low mechanical vibration and noise
·The flow rate is proportional to the rotational speed, suitable for metering purposes
·Strong carrying capacity, high conveying range
·Maintenance free bearings, easy to use, long lifespan
Technical parameters:
·The maximum flow rate can reach 300m3/h, and the maximum pressure can reach 48bar
·Rotor - with wear-resistant and corrosion-resistant coating design, providing multiple material options such as 420, 304, 316, 316L, 2205, Cr12mov, etc
·Stator - imported, specially formulated, providing NBR EPDM、FPM、 Multiple material options including wear-resistant NBR
·Shaft seal - standard single end mechanical seal, low friction resistance, low and high temperature resistance, corrosion resistance, wear resistance, stable and reliable sealing effect. According to the actual working conditions, other types of single/double end mechanical seals, containerized or other types of mechanical seals can also be used, and the sealing of the packing can also be improved.
·Reducer - comes standard with R series helical gear hard tooth surface reducer, which has high load-bearing capacity, high efficiency, and long service life. It can be selected according to the customer's specified brand.
·Motor - Provides various forms of options such as three-phase AC, three-phase frequency conversion, three-phase explosion-proof, and three-phase frequency conversion explosion-proof. It can be selected according to the customer's specified brand and offers high-efficiency motor options.
·Bearing seat - maintenance free dual bearing transmission, good rigidity, can withstand combined radial and axial loads, as well as overturning moments, high stability, easy to use, and long service life.
Application:
Transportation of various low and high viscosity media with or without solid particles in wastewater, chemicals, environmental protection, and chemical industries.
